Introducing the Hikmicro HQ50L Habrok Pro Multi-Spectrum Binocular. The forefront of innovative optical technology, blending outstanding thermal and digital imaging capabilities. Equipped with a 640 x 512 resolution thermal detector and a high sensitivity thermal module with a NETD of less than 15 mK, the HQ50L delivers exceptional clarity and detail recognition, even in challenging weather and light conditions. The device features a 50 mm F1.0 thermal lens that provides a remarkable detection range of up to 2600 meters, making it suitable for various applications such as hunting, birding, and wildlife observation.

In addition to its thermal capabilities, the HQ50L boasts a 4K ultra-high-resolution CMOS digital detector with a 60 mm lens, allowing viewers to capture stunning images with a maximum resolution of 3840 x 2160. The 0.49-inch OLED display, featuring a resolution of 1920 x 1080, ensures vibrant visuals with adjustable contrast and brightness, catering to your specific environment. With a versatile magnification range of 5.5x to 22.0x and a wide field of view, this binocular is optimised for both close-up and distant observations.

Designed for durability and ease of use, the HQ50L is lightweight at just 975 grams and features an ergonomic design, making it comfortable to hold during long periods. It is also rated IP67, meaning it’s resistant to dust and capable of withstanding immersion in water, so you can confidently take it on any adventure. Additionally, it operates in extreme temperatures ranging from -30C to +55C, ensuring reliability under various environmental conditions.

The binocular is equipped with a built-in 1000 m laser rangefinder and an 850 nm IR illuminator, enhancing its functionality for nighttime use with a viewing range of up to 400 meters. Additional features like video recording, snapshot capture, GPS, and a digital magnetic compass offer further utility for outdoor exploration and practical applications. With a replaceable and rechargeable battery pack that provides up to 10.5 hours of continuous operation, the Hikmicro HQ50L Habrok Pro Multi-Spectrum Binocular is the ultimate tool for enthusiasts seeking an unparalleled viewing experience in the field.



Features

  • 4 Colour Palettes
  • 0.49-inch OLED display
  • 7 h+ continuous operation time
  • Built-in EMMC (64 GB) Storage
  • 640 x 512 resolution
  • 12 um thermal detector
  • High sensitivity thermal module
  • Netd < 15 mk (at 25c, f 1.0)
  • 50 mm, f1.0 lens with thermal detection range up to 2600 m
  • 3840 x 2160 4k ultra high-resolution CMOS detector
  • 1920 x 1080 resolution
  • 975 g lightweight, with a compact and ergonomic design
  • Built-in 850 nm IR illuminator and laser rangefinder of 1000 m measuring distance



Specifications

Thermal Module
Image SensorVOx Uncooled Focal Plane Arrays
Max. Resolution640 x 512
Frame Rate50Hz
Pixel Interval12um
Response Waveband8um to 14um
NetdLess than 15 mK (at 25C),F1.0
Lens (Focal Length)50mm, F1.0
Detection Range2600m
Focus ModeFocus Ring
Field Of View(H X V), Degrees / M At 100M8.8 x 5.3 / 15.4m x 9.3m
Min. Focusing Distance5m
Magnification4.3x-20.0x (4.6x)
Optical Module
Image Sensor1/1.8” Progressive Scan CMOS
Max. Resolution3840 x 2160
Field Of View (H X V), Degrees/M At 100 M7.3 x 4.1 / 12.6m x 7.2m
Focal Length60mm, F2.2
Min. Working Distance3m
Ir Illuminator Wavelength850nm
Viewing Range At Night400m
Magnification5.5x – 22.0x4x
Focus ModeFocus Ring
Smart IrYes
Replaceable Ir IlluminatorYes
Image Display
Display0.49 inch, OLED, 1920 x1080
Contrast AdjustmentYes
Brightness AdjustmentYes
PalettesThermal: Black Hot, White Hot, Red Hot, Fusion, Optical: Day, Night, Auto
Ffc (Flat Field Correction) ModeAuto, Manual, External Correction
Exit Pupil8mm
Eye Relief15mm
Diopter (Range)-5D – +3D
Tone AdjustmentCold, warm
Zoom ProYes
Image Pro 2.0Yes
General
Protection LevelIP67
Weight975g with battery pack
Dimension142.9mm x 79.7 mm x 230.5 mm (5.6" x 3.1" x 9.1" Inch)
Working Temperature-30 – +55
Interpupillary Adjustment Range60 mm to 74 mm
Mounting Adapter1/4-20-UNC
System
Record VideoYes
Capture SnapshotYes
HotspotYes
GpsYes
Digital Magnetic CompassYes
Standby ModeYes
StorageBuilt-in EMMC (64 GB)
PipYes
Hot TrackYes
Audio RecordingYes
Local AlbumYes
Power Supply
Battery TypeReplaceable and Rechargeable Li-ion Battery Pack
Battery Operating Time10.5h (25 C, with hotspot off, LRF and Zoom Pro on)
Type-C Power Supply5V/9V DC, 3A
 Support External Power Supply
 Support Direct Charging
Laser Rangefinder
Safety Class For LaserClass 1
Wavelength905nm
Max. Measuring Range1000m
Measurement Accuracy-/+1m
Min. Measuring Range10m
