Introducing the Hikmicro Habrok HQ35L LRF Multi-Spectrum Binocular – 640 x 512. Named after the Norse mythological symbol of excellence, the Habrok series exclusively employs a 35mm objective lens diameter, enhancing portability and eliminating the need for separate stalking binoculars. Unlike its predecessors, the Habrok utilizes round 0.49" OLED displays, providing a viewing experience akin to traditional binoculars.
Ease of use is paramount, with interpupillary distance adjustment and diopter compensation facilitated by movable eyepieces. Six rubberised control buttons atop the housing ensure intuitive menu navigation, even in low-light conditions. Powered by two 18650 rechargeable batteries, the Habrok offers up to 6 hours of continuous operation, with four batteries included for extended field use.
With integrated Wi-Fi connectivity, the Habrok connects seamlessly to the Hikmicro Sight app, offering remote control functionality, firmware updates, and media management. Advanced features include a digital compass, GPS, and position sensor for enhanced usability and energy efficiency. The binoculars feature a 640 x 512 resolution thermal detector with a detection range of 1800m, coupled with a 2560 x 1440 resolution CMOS detector for optimal imaging. With an IP67 waterproof rating and a lightweight, ergonomic design, the Habrok is built for reliability and performance in any environment.
Features
- 1,920 x 1,080 resolution 0.49-inch OLED display
- 6 h+ continuous operation
- Built-in EMMC (64 GB) Storage
- Integrated hotspot module makes sight app as a second display
- Local album for convenient viewing
- Smart IR to avoid overexposure
- Ip67 waterproof rated
- Thermal lens
- Laser range finder
- IR emitter
- Digital lens
- 2,560 x 1,440 high resolution CMOS detectors
- 384 x 288 resolution at 12 m thermal detector
- 780 g lightweight, compact and ergonomic design
- 35 mm, f1.0 lens with thermal detection range up to 1,800 m
- High sensitivity thermal module netd 20 MK (at 25c, f 1.0)
- Built-in 850 nm IR illuminator and laser range finder of 1,000 m measuring distance
Specifications
| Thermal Module | |
| Image Sensor | VOx Uncooled Focal Plane Arrays |
| Max. Resolution | 640 x 512 |
| Frame Rate | 50Hz |
| Pixel Interval | 12um |
| Response Waveband | 8um to 14um |
| Netd | Less than 20 MK (at 25C),F1.0 |
| Lens (Focal Length) | 35mm, F1.0 |
| Detection Range | 1800m |
| Focus Mode | Focus Ring |
| Field Of View(H X V), Degrees / M @100M | 12.5×10.1/ 22.0mx17.6m |
| Min. Focusing Distance | 3.5m |
| Magnification | 3.0x-24.0x (8x) |
| Optical Module | |
| Image Sensor | 1.88” Progressive Scan CMOS |
| Max. Resolution | 2560 x 1440 |
| Min. Illumination | 0.001 lux at (F1.0, AGC On) |
| Field Of View (H X V), Degrees/M @100 M | 13.9×7.8 / 24.4m x 13.6m |
| Focal Length | 31mm, F1.2 |
| Min. Working Distance | 3m |
| Viewing Range At Night | 400m |
| Magnification | 2.9x-23.2x (8x) |
| Focus Mode | Focus Ring |
| Smart IR | Yes |
| Image Display | |
| Display | 0.49 inch, OLED, 1920 x1080 |
| Contrast Adjustment | Yes |
| Brightness Adjustment | Yes |
| Palettes | Thermal: Black Hot, White Hot, Red Hot, Fusion Optical: Day, Night, Auto |
| Ffc (Flat Field Correction) Mode | Auto, Manual, External Correction |
| Exit Pupil | 8mm |
| Eye Relief | 15mm |
| Diopter (Range) | -5D-+3D |
| Tone Adjustment | Cold, Warm |
| Zoom Pro | Yes |
| General | |
| Protection Level | IP67 |
| Weight | 780g without batteries |
| Dimension | 138.2 mm x 68.4 mm x 212.4 mm (5.4" x 2.7" x 8.4") |
| Working Temperature | -30 – +55 |
| Interpupillary Adjustment Range | 60 mm to 74 mm |
| Mounting Adapter | 1/4-20-UNC |
| System | |
| Record Video | Yes |
| Capture Snapshot | Yes |
| Hotspot | Yes |
| Gps | Yes |
| Digital Magnetic Compass | Yes |
| Standby Mode | Yes |
| Storage | Built-in EMMC (64 GB) |
| Pip | Yes |
| Hot Track | Yes |
| Audio Recording | Yes |
| Local Album | Yes |
| Power Supply | |
| Battery Type | Replaceable and Rechargeable Li-ion Battery |
| Battery Operating Time | Roughly 6h (25 C, with hotspot off) |
| Type-C Power Supply | 5V DC, 2 A, Supports External Power Supply |
| Laser Range finder | |
| Safety Class For Laser | Class 1 |
| Wavelength | 905nm |
| Max. Measuring Range | 1000m |
| Measurement Accuracy | +-1m |
| Min. Measuring Range | 10m |
| Infra-red Illuminator | |
| Emitter | LED |
| IR Wavelength | 850nm |
| Beam Angle | Adjustable 7.6-11.5 |
